A286 Stainless Steel U bolts are externally threaded fasteners with an integral head, manufactured per ASME B18.2.1, ISO 4014/4017, and DIN 933/931. TorqBolt produces A286 Stainless Steel U bolts in metric (M6–M100) and imperial (1/4"–4") diameters with custom lengths from 10 mm up to 3000 mm.
A286 Stainless Steel U bolts are supplied with full or partial threading. Full-thread (UNC, UNF, ISO metric coarse/fine) for tension-only joints; partial-thread shank for shear loads where the unthreaded grip carries the load. Thread fits per ASME B1.1 (Class 2A) or ISO 965 (6g) by default; tighter Class 3A / 4h6h fits available on request. Engagement length follows the 1.5×D rule for tapped holes; 1.0×D minimum on through-bolting.
A286 Stainless Steel U bolts achieve characteristic tensile strength, yield, and elongation per the source-material spec, with proof-load testing and hardness verification per ASTM F606 / ISO 898-1. Torque-tension calibration is published per ASME PCC-1 for critical joints. Each lot ships with EN 10204 3.1 (or 3.2 on request) certificates listing chemistry, mechanicals, hardness, and dimensional inspection.
TorqBolt can produce A286 Stainless Steel U bolts to drawing, with non-standard heads, drilled-shank variants, double-end, captive, or matched-set configurations. Coatings include zinc, PTFE, Xylan, hot-dip galvanized, and electroless nickel. NACE MR0175 / ISO 15156 sour-service certification on request.
A-286 (UNS S66286, AISI 660) is an iron-nickel-chromium age-hardenable superalloy positioned between austenitic stainless steels and Inconel for high-temperature bolting at 700-1300°F (370-700°C). Approximately 26% Ni + 15% Cr + 1.25% Mo with Ti-Al precipitation hardening, A-286 retains tensile strength and oxidation resistance well beyond the limits of standard 316 SS while being substantially more economical than full nickel superalloys.
A-286 is the standard high-temperature stud and bolt material for steam turbines, gas-turbine combustor cases, exhaust systems, jet-engine shafts, and superheater bolting. The alloy responds to a two-step heat treatment: solution anneal at 980°C (water quench) followed by ageing at 720°C for ~16 hours, yielding tensile ~895 MPa and yield ~585 MPa with elongation >15%.
A-286 fasteners are supplied per ASTM A453 grade 660 (with class A/B/C/D heat-treat conditions) and AMS 5731 / 5732 / 5734 / 5737. EN 10204 3.1 / 3.2 certification covers chemistry, mechanicals at room temperature + elevated test temperatures, hardness (HRC 24-35), and stress-rupture testing. NACE MR0175 / ISO 15156 sour-service compliance is achievable in specific heat-treat conditions; A-286 is widely qualified for downhole + wellhead bolting.
